Chapter 9 — Solar Radiation Heat Balance And Temperature

Fig 1 — Educational Diagram: Solar radiation

Definition: Solar radiation (insolation) is the energy emitted by the Sun and received at the top of the Earth’s atmosphere and at the Earth’s surface as shortwave electromagnetic radiation. It is the primary source of energy controlling Earth’s weather, climate and temperature distribution.

Components and processes:

• Incoming shortwave radiation: mostly visible and near‑infrared wavelengths arriving from the Sun.
• Reflection: a portion is reflected back to space by clouds, aerosols and the surface (quantified by albedo).
• Scattering: molecules and particles scatter sunlight (Rayleigh scattering explains why sky is blue).
• Absorption: gases, aerosols and the surface absorb radiation and convert it to heat.
• Outgoing longwave radiation: the warmed Earth emits terrestrial (longwave) radiation to space; this exchange establishes the surface energy balance.

Factors controlling intensity of solar radiation at a place:

• Latitude — solar angle decreases away from the equator, reducing intensity.
• Solar zenith angle (angle between Sun’s rays and vertical) — smaller zenith angle (Sun higher) → greater intensity.
• Length of day — longer daylight in summer increases daily total insolation.
• Earth–Sun distance — varies slightly over the year (inverse square law), giving perihelion and aphelion effects.
• Atmosphere — clouds, water vapour, dust attenuate and scatter radiation.
• Surface albedo — bright surfaces (snow) reflect more, reducing net absorbed energy.
• Altitude — thinner atmosphere at higher altitudes can increase surface insolation on clear days.

Solar geometry (useful relations): The instantaneous cosine of the solar zenith angle θ (gives how directly the Sun’s rays strike a horizontal surface) is
cos θ = sin φ · sin δ + cos φ · cos δ · cos ω
where φ = latitude, δ = solar declination, ω = hour angle (ω = 15° × solar hours from noon).

Heat balance (simplified): The surface net radiation (R_n) equals absorbed shortwave minus reflected shortwave plus net longwave exchange:

R_n = (K↓ − K↑) + (L↓ − L↑) = (1 − α)K↓ + L_net

where K↓ = incoming shortwave, K↑ = reflected shortwave, α = albedo, L↓ = downward longwave (atmosphere), L↑ = upward longwave (surface).

Importance: Solar radiation determines temperature patterns, drives evaporation and the hydrological cycle, affects agricultural growth, and is the energy source for solar technologies (panels, heaters).

Fig 2 — Educational Diagram: Earth–Sun relations

Overview: Earth–Sun relations describe how the Earth’s motions and orientation relative to the Sun control the amount and distribution of incoming solar radiation (insolation). These relations explain day/night, seasons, variation of temperature with latitude and time of year, and phenomena such as polar day/night.

Main points:

• Earth’s motions: Rotation (daily spin on its axis) causes day and night. Revolution (annual orbit around the Sun) combined with axial tilt causes seasons.
• Axial tilt: The Earth’s axis is tilted about 23.5° to the plane of its orbit. Because of this tilt, during different times of the year either hemisphere is tilted toward the Sun, changing solar angle and day-length.
• Circle of illumination: The dividing line between day and night. Its tilt relative to meridians changes how much of each hemisphere is illuminated and produces longer or shorter days.
• Key latitudinal markers: Tropic of Cancer and Tropic of Capricorn (±23.5°) delimit the zone where the Sun can be overhead at noon; Arctic and Antarctic Circles (±66.5°) mark limits of at least one 24-hour day or night each year.
• Solstices and equinoxes: At equinoxes (about Mar 21 and Sep 23) declination = 0 and day = night everywhere (≈12 h). At summer solstice (about Jun 21 for N. Hemisphere) the northern hemisphere is maximally tilted toward the Sun (declination ≈ +23.5°); at winter solstice (about Dec 21) it is tilted away (declination ≈ -23.5°).
• Solar declination (δ): Angular position of the Sun north or south of the equator changes through the year and controls noon solar altitude.
• Solar angle and insolation: Insolation intensity at a place depends on the solar zenith (or elevation) angle. Higher solar elevation concentrates energy on a smaller surface and produces more heating. The cosine law links angle and intensity.
• Elliptical orbit: Earth’s orbit is slightly elliptical. Distance to the Sun varies (perihelion ≈ 147.1 million km in early January; aphelion ≈ 152.1 million km in early July), causing ≈7% seasonal variation in received solar energy at the top of the atmosphere—however, the axial tilt, not distance, mainly produces the seasons.

Implications: Changes in solar angle and day length explain seasonal temperature cycles, agricultural seasons, timing of heating and cooling of land and sea (hence monsoon influences), variation of climate with latitude, and extreme polar phenomena such as the midnight sun and polar night.

Fig 3 — Educational Diagram: Solar angles and declination

Overview: Solar angles describe the Sun's apparent position in the sky at any time and place. Declination (δ) is the latitude of the subsolar point — the place on Earth where the Sun is directly overhead at local noon. Declination changes through the year because of Earth's 23.45° axial tilt and its orbit around the Sun.

Key solar angles:

• Solar declination (δ): angular distance of the Sun north or south of the celestial equator. Ranges approx. +23.45° (June solstice) to −23.45° (December solstice), passing 0° at equinoxes.
• Latitude (φ): observer's geographic latitude (positive north, negative south).
• Hour angle (H): angular measure of time before/after local solar noon: H = 15° × (local solar time − 12). At solar noon H = 0°.
• Solar zenith angle (θz): angle between the vertical (zenith) and the line to the Sun. When Sun is overhead θz = 0°.
• Solar altitude/elevation (α): angle between the horizon and the Sun: α = 90° − θz.
• Solar azimuth (A): compass direction of the Sun measured from a reference (commonly from north or south; sign conventions vary).

Relationships (geometry):

• Cosine of the solar zenith angle (fundamental relation):
  cos θz = sin φ · sin δ + cos φ · cos δ · cos H
• Solar altitude (useful form):
  sin α = sin φ · sin δ + cos φ · cos δ · cos H
• At local solar noon (H = 0): α_noon = 90° − |φ − δ| (or equivalently α_noon = 90° − θz with θz = |φ − δ| when Sun on meridian).

Declination variation through the year (approximate):

Declination can be approximated by a simple sinusoidal formula (Cooper approximation):
δ = 23.45° · sin[360° · (284 + n) / 365], where n is the day number of the year (n = 1 on Jan 1). This yields δ ≈ 0° at equinoxes, +23.45° on about June 21, and −23.45° on about Dec 21.

Sunrise/sunset and day length:

• Sunrise/sunset hour angle H0 (degrees) from cos H0 = −tan φ · tan δ.
• Day length (hours) = (2/15) · H0 where H0 is in degrees (because Earth rotates 15° per hour).

Solar azimuth (common formula, watch sign conventions):

• sin A = (cos δ · sin H) / cos α
• cos A = (sin δ − sin φ · sin α) / (cos φ · cos α)

Physical meaning & real-life importance: Solar angles determine intensity and distribution of incoming solar radiation on Earth’s surface. Higher solar altitude (smaller zenith angle) gives more concentrated sunlight and higher heating. Declination controls seasonal changes in day length and midday Sun height, driving climates, growing seasons, and energy available for solar panels.

Fig 4 — Educational Diagram: Day length and seasons

Basic cause: Seasons and day length changes are caused by the tilt of Earth's rotational axis (about 23.45°) relative to its orbital plane and by Earth's annual revolution around the Sun. Because of this tilt the latitude at which the Sun is directly overhead (solar declination) changes through the year between +23.45° (Tropic of Cancer) and -23.45° (Tropic of Capricorn).

Day length — concept: Day length (hours of daylight) at a place and date is controlled by two factors: the Sun’s declination (δ) on that date and the observer’s latitude (φ). When the Sun’s centre crosses the local meridian at solar noon, the hour angle from noon to sunrise (ω0) satisfies:

ω0 = arccos( - tan φ · tan δ )

Day length (DL) in hours is obtained by converting the total angle (2ω0) to time (15° = 1 hour):

DL = (2 · ω0) / 15

If |tan φ · tan δ| > 1 the arccos argument falls outside [-1,1]; this indicates polar day (24 h daylight) or polar night (0 h daylight) depending on the signs of φ and δ.

Seasons — how day length contributes: Seasons arise from two linked effects of tilt and revolution:

• Change of solar declination (δ) through the year changes the Sun’s maximum altitude at noon. Higher noon Sun = greater intensity of incoming solar radiation.
• Change of declination also changes day length at each latitude. Longer days increase the daily total insolation; shorter days reduce it.

Together, change in solar angle and change in day length produce the seasonal cycle of temperature and weather: in summer a hemisphere has higher solar altitude plus longer days → more net heating; in winter lower solar altitude plus shorter days → cooling. Hemispheres experience opposite seasons at the same time (when northern summer, southern winter).

Special cases:

• Equinoxes (about 21 March, 23 Sept): δ ≈ 0 → DL ≈ 12 hours at all latitudes (ignoring atmospheric refraction and twilight).
• Solstices (about 21 June, 21 Dec): δ ≈ +23.45° (June) or -23.45° (December) produce maximum north–south contrast in day length. Areas beyond the Arctic/Antarctic circles (φ > 90° − 23.45° ≈ 66.55°) have at least one 24 h day (midnight sun) and one 24 h night each year.

Practical consequences: Longer summer days in high latitudes allow extended outdoor activities, affect plant growing seasons and agricultural calendars, and cause seasonal variation in energy demand (e.g., more cooling demand in summer, more heating in winter). The midnight sun in polar regions influences ecosystems and human life; tourists visit high-latitude regions in summer for continuous daylight.

Fig 5 — Educational Diagram: Distribution of insolation

What is insolation? Insolation is incoming solar radiation received at the top of the atmosphere or at the Earth's surface. Its distribution over the Earth controls temperature patterns and climate.

Main controls on distribution of insolation

• Latitude and angle of incidence (cosine law): When the Sun is overhead, solar rays are concentrated on a small surface area; at low solar elevation they spread over a larger area. The instantaneous irradiance varies approximately with the cosine of the solar zenith angle (θ): I ∝ cos θ. Thus, for the same solar input at the top of the atmosphere, low latitudes receive more intense radiation than high latitudes.
• Day length (duration of sunlight): Higher latitudes have longer days in summer and shorter days in winter. Longer daylight increases daily sunshine total; together with solar elevation it determines seasonal contrasts.
• Season and solar declination (tilt of Earth): Earth's axial tilt (≈ 23.5°) causes the Sun’s declination to change through the year, producing seasons. When the hemisphere tilts toward the Sun, that hemisphere receives higher solar elevations and longer days.
• Atmospheric path and transparency: When the Sun is low, solar rays travel a longer path through the atmosphere, increasing scattering and absorption (by gases, aerosols, water vapor). Clear dry air and high altitude increase surface insolation; clouds and humidity reduce it.
• Earth–Sun distance: Because Earth's orbit is slightly elliptical there is a small annual change (~±3.3%) in solar irradiance (maximum at perihelion ~ early January, minimum at aphelion ~ early July). This is much smaller than seasonal effects from tilt.
• Surface albedo: Bright surfaces (snow, ice, deserts) reflect a large fraction of incoming radiation, reducing net radiation absorbed at the surface. Dark surfaces absorb more.
• Local factors: Altitude, topography, coastal vs continental position, aerosols and pollution, and vegetation cover all modify actual insolation at the surface.

Spatial and temporal patterns (summary)

• At equinoxes, day length is ~12 h everywhere and the equator gets the highest, most consistent daily insolation; high latitudes receive much less because of low solar elevation.
• At solstices, the hemisphere tilted toward the Sun gets higher daily and seasonal insolation (summer), the other hemisphere gets lower (winter). Above the Arctic/Antarctic circles there are polar day/night.
• Annual total insolation decreases generally from equator to poles, but local weather, clouds and surface albedo cause regional deviations.

Typical values

• Solar constant (top of atmosphere): S0 ≈ 1361 W/m².
• Maximum clear-sky surface irradiance at solar noon: roughly 900–1100 W/m² (depends on atmosphere and altitude).
• Daily insolation (surface) commonly expressed in MJ/m²/day: low latitudes 15–30 MJ/m²/day; mid-latitudes vary widely with season.

Why this matters for weather and climate: The latitudinal and seasonal differences in insolation create the large-scale temperature contrasts that drive atmospheric circulation (Hadley, Ferrel, Polar cells), monsoons and prevailing winds.

Fig 6 — Educational Diagram: Atmospheric effects on radiation

What it means
Atmospheric effects on radiation describe how the Earth's atmosphere alters incoming solar (shortwave) radiation and outgoing terrestrial (longwave) radiation before they reach the ground or escape to space. The main processes are absorption, scattering, reflection, refraction and transmission. These processes determine how much energy reaches the surface, how it is distributed spectrally and spatially, and how energy is retained in the climate system.

Major processes

• Absorption — Certain gases and particles take up radiation at specific wavelengths and convert it to heat. Examples: ozone (O3) strongly absorbs UV, water vapour (H2O) and carbon dioxide (CO2) absorb infrared. Absorption reduces direct solar irradiance and controls atmospheric heating and the greenhouse effect.
• Scattering — Change of direction of radiation by molecules and aerosols. Rayleigh scattering (by air molecules) is wavelength-dependent (~1/λ⁴) and makes the sky blue and the Sun red at sunrise/set. Mie scattering (by larger aerosols, dust, pollution) is less wavelength-dependent and causes haze and whitening of the sky.
• Reflection — Mirror-like return of radiation by clouds, aerosols and the surface. Clouds have high reflectivity and raise planetary albedo; surfaces like snow/ice reflect large fractions of shortwave radiation.
• Refraction — Bending of radiation as it passes through air layers of different density; important for apparent solar position at sunrise/set and for phenomena like mirages.
• Transmission and the atmospheric window — Some wavelengths (notably much of the visible) pass through the atmosphere with little absorption. In the thermal infrared there is an "atmospheric window" (roughly 8–14 µm) through which the surface can radiate directly to space.

Effects on shortwave and longwave radiation
Incoming solar radiation (shortwave) is reduced by scattering and absorption: the flux at the top of atmosphere (TOA) is the solar constant (~1361 W m^-2), but the direct flux at ground depends on solar zenith angle, optical thickness (aerosols, water vapour), and clouds. Outgoing terrestrial radiation (longwave) is strongly affected by greenhouse gases and clouds which absorb and re-emit IR, trapping heat and warming the surface (greenhouse effect).

Quantitative ideas useful at Class 11 level

• Solar constant S₀ ≈ 1361 W m^-2 (flux at 1 AU perpendicular to Sun's rays)
• Average incoming at TOA = S₀/4 ≈ 340 W m^-2 (averaged over the whole spherical Earth)
• Air mass and path length — Radiation traverses a longer path when the Sun is low. Path length is often approximated by air mass m ≈ 1/cos z (z = solar zenith angle). Greater m → more absorption and scattering.
• Attenuation (Beer–Lambert type) — Intensity falls roughly exponentially with optical depth: I = I₀ e^-τ/μ, where τ is optical depth, μ = cos z (or m ≈ 1/μ). This explains why dawn/dusk are much redder and dimmer than noon.

Climate and weather implications
Atmospheric effects control surface temperatures, diurnal range (clear skies → large day–night swings; cloudy nights → warmer), visibility and UV exposure. Aerosols and clouds modify the radiation budget regionally and can either cool (by reflecting solar) or warm (by absorbing and trapping terrestrial IR).

Practical importance

• Solar energy: panel output depends on direct vs diffuse radiation and incidence angle.
• Health: ozone layer protects against harmful UV; air pollution affects solar radiation and human health.
• Cryosphere: deposition of dark aerosols on snow reduces albedo and accelerates melting.

Fig 7 — Educational Diagram: Albedo and reflectivity

Definition: Albedo (or reflectivity) is the fraction of incoming solar radiation that a surface or body reflects back to space. It is a dimensionless ratio between 0 and 1 (or 0%–100%).

Simple formula: albedo α = (reflected solar radiation) / (incident solar radiation).

Types and terms:

• Surface albedo — reflectivity of a particular ground cover (snow, water, vegetation, etc.).
• Planetary (Bond) albedo — fraction of total incident solar energy reflected by a planet integrated over all wavelengths and directions.
• Spectral albedo α(λ) — albedo measured as a function of wavelength λ (important because surfaces reflect differently in visible and infrared).
• Geometric albedo — brightness of a body at zero phase angle relative to a flat, fully reflecting disk.

Key relationships (energy view):

• For opaque surfaces (no transmission): reflectivity R + absorptivity A = 1, so R = 1 − A.
• Planetary absorbed solar energy (average) = (1 − α) × S0 / 4, where S0 is the solar constant.

Importance for climate and temperature:

• Higher albedo means more solar energy is reflected and less is absorbed, cooling the surface/planet; lower albedo increases absorption and warming.
• Ice-albedo feedback: melting ice exposes darker surfaces (ocean/land) that have lower albedo, increasing absorption and further warming — a positive feedback important in polar amplification.
• Human impacts: urban surfaces (asphalt) have low albedo, increasing heat (urban heat island); reflective roofs/painting can reduce local temperatures.

Measurement methods: albedometers and pairs of pyranometers (to measure upwelling and downwelling shortwave radiation), and remote-sensing satellites which map spectral and spatial variations.

Worked example (planetary equilibrium temperature): Using the balance (1 − α) S0 / 4 = σT^4, with S0 ≈ 1361 W m−2 and α ≈ 0.30 (Earth's average), the absorbed flux ≈ (0.70×1361)/4 ≈ 238 W m−2. Solving gives T ≈ 255 K (≈ −18 °C), the effective blackbody temperature of Earth without greenhouse warming. The actual surface mean is ≈ 288 K because of atmospheric greenhouse effect.

Factors affecting albedo: surface colour and material, moisture, angle of incoming radiation (solar zenith angle), surface roughness, snow/ice cover, cloud cover, and vegetation stage.

Practical takeaways for students:

• Remember albedo between 0 (all absorbed) and 1 (all reflected).
• Small changes in large-area albedo (ice cover, forests, cities) can cause significant changes in absorbed solar energy.
• Consider spectral effects: e.g., green vegetation reflects more in near-infrared than visible.

Fig 8 — Educational Diagram: Terrestrial (longwave) radiation and greenhouse effect

Terrestrial (longwave) radiation is thermal infrared energy emitted by the Earth–atmosphere system because of its temperature. Unlike incoming solar radiation (shortwave, peak near 0.5 µm), terrestrial radiation is emitted at much longer wavelengths (roughly 4–100 µm) with a spectral peak near ~10 µm because the Earth's surface temperature is around 250–320 K.

Key physical principles

• Any object with temperature >0 K emits radiation; emission intensity depends on temperature (Stefan–Boltzmann law) and spectral peak follows Wien's displacement law.
• Longwave radiation from the warm surface is partly absorbed and re-emitted by atmospheric gases; this interaction controls the vertical and global heat balance.

Greenhouse effect — mechanism

• The Sun supplies shortwave radiation that mostly passes through the atmosphere and warms the surface. The surface then emits longwave (infrared) radiation.
• Certain atmospheric gases (water vapour, CO2, CH4, N2O, ozone) absorb much of that outgoing longwave radiation at specific wavelengths and re-emit it in all directions, including back toward the surface.
• The downward longwave emission from the atmosphere raises the equilibrium temperature of the surface compared with a planet with no absorbing atmosphere. This warming is the greenhouse effect.

Important concepts

• Atmospheric window: parts of the IR spectrum (roughly 8–13 µm) where the atmosphere is relatively transparent so some longwave energy escapes directly to space.
• Outgoing Longwave Radiation (OLR): the net longwave energy leaving the top of the atmosphere; OLR balances absorbed solar radiation in long-term equilibrium.
• Enhanced greenhouse effect: increases in greenhouse gas concentrations reduce OLR for a given surface temperature, producing radiative forcing that tends to warm the surface until a new balance is reached.

Simple quantitative view (energy balance)

• Solar constant S ≈ 1361 W m⁻²; average solar flux received per unit Earth surface = S/4 because of spherical geometry.
• With planetary albedo α (≈0.30 for present Earth), absorbed solar flux per unit area = (1−α)S/4.
• Effective emission temperature of Earth (if it emitted as a blackbody to space without atmosphere): T_e = [(1−α)S/(4σ)]^(1/4) ≈ 255 K.
• Observed global mean surface temperature T_s ≈ 288 K. The difference (~33 K) is due to the greenhouse effect.

Limitations & notes

• Idealized models (e.g., single-layer atmosphere that is perfectly absorbing in longwave) help illustrate the mechanism but over-simplify real atmosphere behaviour (partial absorption, vertical structure, convection, clouds).
• Clouds both reflect shortwave (cooling) and absorb/emit longwave (usually warming at night); their net effect depends on cloud type and height.

Why it matters

The greenhouse effect is essential for a habitable climate. However, human-caused increases in greenhouse gases amplify the natural effect (enhanced greenhouse effect), altering the Earth's energy balance and raising global temperatures—this is the main driver of recent global warming.

Fig 9 — Educational Diagram: Heat transfer processes

Overview: Heat transfer processes describe how energy (heat) moves between the Sun, atmosphere, land and oceans. In physical geography these processes determine temperature patterns, weather and climate. The main processes are radiation, conduction, convection (and advection), and latent heat transfer; together they control the surface energy balance.

1. Radiation
Radiation is the transfer of energy by electromagnetic waves. The Sun emits shortwave radiation (visible and near‑infrared) which reaches Earth; the Earth and atmosphere emit longwave (terrestrial) infrared radiation. Radiation does not require a medium.

• Incoming shortwave (solar) radiation is partly reflected (by clouds, snow — albedo) and partly absorbed by the surface and atmosphere.
• Outgoing longwave radiation is emitted by the surface and atmosphere; greenhouse gases absorb and re‑emit some longwave radiation, warming the atmosphere.

2. Conduction
Conduction is heat transfer through direct contact within solids (or between solid surface and adjacent air by molecular contact). It is important in the soil, rock and the thin air layer immediately next to the ground (soil‑air interface). Conduction is generally slow compared with convection and radiation.

3. Convection and Advection
Convection is vertical heat transfer by fluid motion (air or water). Warm air rises (low density) and cool air sinks, producing convective currents and vertical mixing. Advection is horizontal transport of heat by wind or ocean currents (e.g., warm ocean currents transporting heat poleward).

4. Latent Heat Transfer (Phase changes)
Latent heat is absorbed or released when water changes phase (evaporation, condensation, freezing, melting). Evaporation uses energy (cooling the surface); condensation releases energy (warming the air). Latent heat transfer is a major heat transfer mechanism in the atmosphere and central to weather processes (cloud formation, storms).

5. Sensible Heat and Turbulent Fluxes
Sensible heat flux refers to heat transferred that changes temperature (detectable by a thermometer). In the atmosphere most sensible heat transfer away from the surface is by turbulent eddies — a combination of convection and mechanical mixing by wind.

6. Surface Energy Balance (how processes combine)
The surface energy budget at any location expresses how incoming energy is partitioned:

Rn = H + LE + G + S

Where Rn is net radiation (incoming minus outgoing radiation), H is sensible heat flux, LE is latent heat flux (L is latent heat of vaporization, E is evaporation rate), G is ground heat flux (conduction into soil), and S is storage/change in heat (often small over daily cycles or included in G).

Spatial and temporal differences
- Over deserts: high net radiation → larger sensible heat flux, small LE (little moisture) → high surface temperatures.
- Over oceans: much net radiation goes into LE (evaporation) and G (mixed layer), moderating temperature change.
- Diurnal cycle: daytime strong shortwave input → peaks in Rn, convection and turbulent flux increase; at night outgoing longwave dominates → radiative cooling and possible temperature inversions.

Importance: Understanding these processes explains sea/land breezes, monsoon dynamics, urban heat islands, frost formation, cloud development and climate feedbacks.

Fig 10 — Educational Diagram: Heat budget and energy balance

Definition
Heat budget (or energy balance) describes how incoming solar energy is distributed, stored and returned by the Earth–atmosphere system. At any location the balance between incoming radiation and outgoing energy determines heating or cooling of the surface and atmosphere.

Main components

• Incoming shortwave radiation (SW↓): Solar radiation reaching the top of atmosphere (~1361 W/m², the solar constant). The average over the whole Earth surface is S0/4 ≈ 340 W/m².
• Reflected shortwave (SW↑): Part of SW↓ reflected back to space. Fraction reflected = surface + atmospheric albedo (global mean ≈ 0.30).
• Absorbed solar (ASR): SW absorbed by atmosphere + surface = SW↓(1 − α).
• Incoming longwave (LW↓): Back radiation from atmosphere and clouds toward the surface.
• Outgoing longwave (LW↑): Thermal radiation emitted by the Earth’s surface to the atmosphere/space (depends on surface temperature).
• Net radiation (Rn): Balance of shortwave and longwave at the surface and is the source of energy for surface processes.
• Sensible heat flux (H): Heat transfer between surface and air by conduction/convection; raises air temperature.
• Latent heat flux (LE): Energy used for evapotranspiration (evaporation + transpiration); cools the surface.
• Ground (soil) heat flux (G): Energy conducted into or out of the ground; important at daily timescales.

Surface energy balance (local)
At the surface, the short-term (daily) energy balance is commonly written as:

Rn = H + LE + G

where Rn is net radiation available at the surface and the right-hand terms are sinks (sensible, latent, and ground heat flux). For longer periods a storage term (ΔS) or other fluxes may be included so that Rn + other inputs = H + LE + G + ΔS.

Net radiation detailed form
Expressed using components of radiation:

Rn = SW↓(1 − α) + LW↓ − LW↑

Outgoing longwave from a surface can be estimated by Stefan–Boltzmann law (for an ideal emitter):

LW↑ ≈ εσT⁴

where ε is emissivity (~0.95–1 for most natural surfaces), σ = 5.67 × 10⁻⁸ W m⁻² K⁻⁴ and T is absolute temperature (K).

Global energy balance (planetary)
Over long-term global average, absorbed solar radiation ≈ outgoing longwave radiation (radiative equilibrium). Typical global mean values (approximate): incoming solar at TOA ~340 W/m², reflected ~100 W/m² (albedo ≈ 0.30), absorbed ≈240 W/m², outgoing longwave ≈240 W/m². Any long-term imbalance drives climate change.

Controls and consequences
Distribution of net radiation varies by latitude (surplus in tropics, deficit at poles), season, time of day, surface type (albedo), cloud cover, and atmospheric composition (greenhouse gases). Surplus energy in low latitudes is transported poleward by the atmosphere and oceans, maintaining global climate gradients.

Fig 11 — Educational Diagram: Surface heat balance components

What is surface heat balance? The surface heat balance describes how incoming and outgoing radiation and energy fluxes at Earth's surface are distributed. The balance determines heating or cooling of the surface and the atmosphere above it and controls processes such as evaporation, convection and soil warming.

• Incoming shortwave radiation (K↓) – solar radiation reaching the surface (visible and near‑infrared). It varies with time of day, season, cloud cover and latitude.
• Reflected shortwave radiation (K↑) – part of K↓ reflected back to the atmosphere. The fraction reflected is the albedo (α). Snow and ice have high α; vegetated surfaces and oceans have low α.
• Net shortwave radiation (K* or Knet) – the shortwave energy retained: K* = K↓ − K↑ = (1 − α)K↓.
• Incoming longwave radiation (L↓) – thermal radiation from the atmosphere (including clouds) toward the surface. It increases with atmospheric temperature and cloudiness.
• Outgoing longwave radiation (L↑) – terrestrial (thermal) radiation emitted by the surface, approximately given by the Stefan–Boltzmann relation for a body at temperature T.
• Net longwave radiation (L* or Lnet) – the difference: L* = L↓ − L↑. Often negative by day when the surface emits more than it receives (but clouds can make it less negative).
• Net radiation (Rₙ) – the net gain of radiative energy at the surface: Rₙ = K* + L* = K↓ − K↑ + L↓ − L↑. Units: watts per square metre (W m⁻²).
• Partitioning of net radiation – the net radiation is used in different ways:
  • Sensible heat flux (H): heating of the air by conduction and convection (warming the air layer).
  • Latent heat flux (LE): energy used for evaporation or transpiration (phase change of water).
  • Ground/soil heat flux (G): energy conducted into or out of the soil (warming or cooling of ground layers).
  • Storage term (S): change in heat stored in vegetation, buildings or deeper ground (sometimes combined with G in short-term balances).
• Surface energy (heat) balance equation – expressing conservation of energy:

  Rₙ = H + LE + G + S

  In many short-term or simple studies S is small and Rₙ ≈ H + LE + G.

Behaviour in time and space: Rₙ is usually positive during daytime (surface gains energy) and negative at night. Humid surfaces (forests, irrigated fields) convert a larger fraction of Rₙ into LE (evaporation), while dry or urban surfaces convert more into H (sensible heating). Snow/ice surfaces have high albedo, so K* and thus Rₙ are low or even negative, reducing melting unless longwave inputs are large.

Why it matters: The partitioning controls temperature changes, humidity, cloud formation, and local climate features such as the urban heat island and regional differences between deserts and forests.

Typical magnitudes (order of magnitude): shortwave midday K↓ at the surface may reach a few hundred to ~1000 W m⁻² under clear skies; net radiation and flux terms are typically in the range of tens to several hundreds W m⁻² depending on conditions.

Simple example (qualitative): On a sunny summer day over a wet grassland, much of Rₙ becomes LE (evaporation & transpiration) so air temperature rises slowly; over dry bare ground, LE is small and more energy becomes H and G, so the air and ground warm rapidly.

Fig 12 — Educational Diagram: Specific heat and thermal properties

Definition (specific heat): Specific heat capacity (often shortened to 'specific heat') of a substance is the amount of heat energy required to raise the temperature of 1 kilogram of that substance by 1 kelvin (or 1°C). It is written as c and has SI units J kg⁻¹ K⁻¹.

Basic formula: Q = m c ΔT, where Q is heat (J), m is mass (kg), c is specific heat (J kg⁻¹ K⁻¹) and ΔT is change in temperature (K or °C).

Other thermal properties relevant to geography:

• Heat capacity (C): total heat required to change the temperature of a body. C = m c. For surface layers, heat capacity per unit area is often used (J m⁻² K⁻¹).
• Thermal conductivity (k): ability of a material to conduct heat (W m⁻¹ K⁻¹). Controls how quickly heat flows through a material.
• Thermal diffusivity (α): rate at which a temperature disturbance moves through a material. α = k / (ρ c), where ρ is density. Units: m² s⁻¹. Low α means slow propagation of temperature changes (large thermal inertia).
• Albedo: fraction of incoming solar radiation reflected by a surface (dimensionless). High albedo means less energy absorbed and lower heating.
• Emissivity and Stefan-Boltzmann relation: emissivity ε (0–1) affects longwave radiation; emitted power per unit area E = ε σ T⁴ (σ = Stefan–Boltzmann constant).
• Latent heat: energy absorbed or released during phase changes (e.g., evaporation, condensation) that does not change temperature but affects heat balance.

Why specific heat and thermal properties matter in geography:

• Different materials (water, soil, rock, air) have different specific heats and conductivities. Water has a very high specific heat, so it stores large amounts of heat with small temperature change. Land materials generally have lower specific heat and often higher thermal diffusivity, so they heat and cool faster.
• This difference explains important climate features: small diurnal and seasonal temperature ranges over oceans and coastal areas, larger ranges over continents, and the lag of seasonal maximum temperatures relative to maximum insolation (thermal inertia).
• Soil moisture increases heat capacity and thermal conductivity of soil, modifying ground temperature changes and evaporation rates—important for local climate and vegetation.

Key conceptual points:

• High specific heat → slow temperature change for a given heat input (ocean moderates climate).
• High thermal conductivity → fast transfer of heat through a material (metals conduct heat quickly; air is a poor conductor).
• Low thermal diffusivity → surface temperature variations are confined to a thin layer and penetrate slowly with depth; important for diurnal and seasonal temperature profiles in soil and water.
• Latent heat processes (evaporation and condensation) can remove or add large amounts of energy without temperature change and strongly influence local and regional heat budgets.

Typical values (approximate): specific heat: water ≈ 4,200 J kg⁻¹ K⁻¹; air (at constant pressure) ≈ 1,005 J kg⁻¹ K⁻¹; dry soil ≈ 700–1,000 J kg⁻¹ K⁻¹; ice ≈ 2,100 J kg⁻¹ K⁻¹. Thermal conductivity: water ≈ 0.6 W m⁻¹ K⁻¹; dry soil ≈ 0.25–2 W m⁻¹ K⁻¹ (depends on moisture); rock ≈ 2–3 W m⁻¹ K⁻¹; metals much higher. Thermal diffusivity examples: air ≈ 2×10⁻⁵ m² s⁻¹, water ≈ 1.4×10⁻⁷ m² s⁻¹, dry sand ≈ 1×10⁻⁶ m² s⁻¹.

Implications for weather and climate:

• Coastal regions: ocean's large specific heat causes smaller temperature ranges and delayed seasonal peaks (seasonal lag).
• Continental interiors: low surface heat capacity and often lower humidity produce large diurnal and annual temperature ranges.
• Urban areas: materials with different heat capacities and conductivities plus reduced evapotranspiration produce urban heat island effects.
• Soil temperature profiles: amplitude of diurnal/seasonal variation decreases with depth; the phase of maximum temperature is delayed with depth because of thermal diffusivity.

Summary: Specific heat and related thermal properties determine how different surfaces absorb, store and release heat. These properties drive many everyday and large-scale geographic phenomena such as sea breezes, continentality, diurnal ranges, and seasonal temperature lags.

Fig 13 — Educational Diagram: Temperature: measurement and scales

What is temperature?
Temperature is a measure of the average kinetic energy of air molecules. In meteorology and physical geography it describes the degree of hotness or coldness of the atmosphere at a given place and time.

How temperature is measured (practical aspects)

• Standard practice: Air temperature for weather observations is measured in the shade, with instruments housed in a ventilated white shelter (Stevenson screen) about 1.2–2.0 m above ground to avoid direct solar heating and ground effects.
• Common instruments:
  • Mercury-in-glass thermometer – traditional, accurate for a wide range of temperatures (not for very low temps below mercury freezing).
  • Alcohol (spirit) thermometer – uses dyed alcohol, safe and suitable for very low temperatures.
  • Maximum and minimum (Six's) thermometer – records highest and lowest temperatures between readings using an index in the tube; useful for daily extremes.
  • Electronic thermometers (thermistors, RTDs, thermocouples) – fast response, used in automated weather stations; thermocouples for wide ranges, RTDs for high accuracy.
  • Infrared (IR) thermometers and satellite sensors – measure surface temperature remotely (land surface temperature), useful in weather satellites and remote sensing.
• Special instruments/concepts: Wet-bulb and dry-bulb thermometers (psychrometer) are used to derive humidity and dew point; standard exposure and sheltering ensure comparable measurements worldwide.

Scales of temperature

• Celsius (°C) – common in India and scientific work; 0°C is freezing point of water, 100°C is boiling point (at 1 atm).
• Fahrenheit (°F) – used mainly in the United States; 32°F is freezing, 212°F is boiling (at 1 atm).
• Kelvin (K) – the SI absolute scale used in science; 0 K (−273.15°C) is absolute zero. No degree sign is used.

Important derived concepts and indices

• Maximum temperature (Tmax) – highest air temperature recorded in a 24-hour period.
• Minimum temperature (Tmin) – lowest air temperature recorded in a 24-hour period.
• Mean daily temperature – often taken as (Tmax + Tmin) / 2 or from continuous measurements averaged over 24 h.
• Monthly mean temperature – average of daily means for a month.
• Annual range of temperature – difference between the warmest and coldest monthly means (an index of continentality).
• Diurnal range – daily difference between Tmax and Tmin (high in deserts, low near coasts).
• Lapse rate – rate at which air temperature decreases with altitude (environmental lapse rate ≈ 6.5°C per 1000 m on average).

Why measurement method and scale matter
Accurate sheltering, instrument type, and measuring height are essential for comparable observations. Choice of scale matters for calculations, reporting, and converting to absolute temperature for physical formulas.

Summary
Temperature measurement combines correct instrumentation, exposure, and standard scales (°C, °F, K). From single-day extremes to long-term monthly means, temperature data are central to climatology, weather forecasting, agriculture and everyday life.

Fig 14 — Educational Diagram: Diurnal and seasonal temperature variations

Diurnal temperature variations are the changes in air temperature that occur during a single day (24 hours). Temperatures rise after sunrise as incoming shortwave solar radiation exceeds outgoing terrestrial radiation, reach a maximum usually in the early to mid‑afternoon (around 14:00–15:00 local time), then fall through the evening and reach a minimum just before sunrise. The lag between peak insolation and peak temperature is due to the time required for the surface and the air above it to warm.

Major controls on diurnal range (difference between daily maximum and minimum) include:

• Surface heat capacity: Water and moist soils store heat and reduce diurnal range; dry sand and rock heat and cool quickly, increasing the range.
• Cloud cover: Clouds reduce daytime heating and reduce night‑time loss by longwave back‑radiation — both effects decrease diurnal range.
• Humidity: More water vapour increases atmospheric heat capacity and longwave trapping, reducing range.
• Wind and mixing: Strong winds mix air, moderating extremes and reducing the range.
• Latitude and solar angle: Higher solar angles (low latitudes) give stronger daytime heating; but maritime influence often dominants near coasts.
• Altitude: Thinner air at high altitudes cools quickly at night, often increasing diurnal range.

Seasonal temperature variations are the changes in mean temperature over the year caused primarily by the Earth’s axial tilt (about 23.5°) which changes the solar declination and day length through the seasons. When a hemisphere tilts toward the Sun it receives higher solar angle and longer days (summer); when tilted away it receives lower angles and shorter days (winter).

Important aspects of seasonal variation:

• Seasonal lag: Maximum and minimum monthly mean temperatures usually occur after the dates of maximum and minimum insolation (e.g., hottest month comes some weeks after summer solstice) because of heat storage in the ground and oceans.
• Continentality vs. maritime effect: Continental interiors show larger annual ranges because land warms and cools quickly; oceanic locations show smaller ranges because water moderates temperature.
• Latitude: Annual range generally increases with latitude (except where oceans moderate it). Polar regions experience extreme seasonal contrasts (polar day/night), tropics have small seasonal temperature variation.
• Altitude and topography: Higher elevations are cooler year‑round and may show different seasonal amplitudes depending on local radiation and air mass effects.
• Ocean currents and atmospheric circulation: Warm currents (e.g., Gulf Stream) raise temperatures and reduce contrasts; cold currents do the opposite. Monsoon circulations and prevailing winds also modify seasonal patterns.

Practical consequences include timing of growing seasons, heating/cooling demands, daily comfort, frost occurrence, and desert temperature stresses. Understanding diurnal and seasonal variations is essential for agriculture, urban planning and climate studies.

Fig 15 — Educational Diagram: Factors controlling temperature distribution

Overview: Temperature distribution over the Earth is controlled by several physical factors that determine how much solar energy a place receives, how that energy is modified, stored and lost. The main controls are latitude, altitude, distance from the sea (continentality), ocean currents, prevailing winds and air masses, topography and aspect, cloud cover and precipitation, vegetation and soil, and human activities. These factors work together to produce the climatic and daily/seasonal temperature patterns we observe.

1. Latitude
Latitude is the primary control. Solar rays strike the Earth at different angles: at low latitudes rays are near vertical and concentrated; at high latitudes they are oblique and spread out. Also day length varies with latitude and season. Result: warmer climates near the equator and colder toward the poles.

2. Altitude (Height above sea level)
Temperature generally decreases with height in the troposphere because air pressure falls and rising air expands and cools. The average environmental lapse rate is about 6.5°C per km. High-altitude places (e.g., Quito, La Paz) are cooler than lowlands at the same latitude.

3. Distance from the sea (Continentality vs Maritime influence)
Water has a high heat capacity and moderates temperature changes. Coastal (maritime) locations experience smaller diurnal and seasonal ranges; inland (continental) locations have larger ranges and more extreme highs and lows. Example: Western Europe (maritime) is milder than Siberia (continental) at similar latitudes.

4. Ocean currents
Warm currents raise coastal air temperatures and cold currents lower them. Currents also influence humidity and precipitation. Example: Gulf Stream keeps north-west Europe warmer; the cold Humboldt Current cools Peru’s coast and helps create deserts.

5. Prevailing winds and air masses
Winds bring the thermal properties of their source regions. Polar air masses make areas colder; tropical maritime air masses make them warmer and moister. Föhn/Chinook winds produce rapid warming on lee slopes due to adiabatic compression.

6. Topography and aspect
Slopes facing the Sun (southern slopes in the Northern Hemisphere) receive more solar radiation and are warmer than shaded slopes. Mountain valleys may trap cold air at night (temperature inversion), leading to cooler valley floors than slopes.

7. Cloud cover and precipitation
Clouds reduce incoming solar radiation (cooling daytime) and act as an insulating blanket at night (reducing cooling). Regions with persistent cloud cover thus often have lower daytime maxima and higher nighttime minima—smaller diurnal range.

8. Vegetation and soil
Vegetation shades the surface and uses energy in evapotranspiration, cooling the surface. Dark soils and rock absorb more heat (lower albedo) and warm faster than light-colored surfaces.

9. Human activities
Urbanization, deforestation and industrial heat release modify temperatures. The urban heat island effect makes cities several degrees warmer than surrounding rural areas (reduced vegetation, dark surfaces, waste heat).

Interactions & Energy Budget
Temperature at any place is the result of the local energy balance. Key components: incoming solar (shortwave) radiation, reflected shortwave (albedo), outgoing longwave (terrestrial) radiation, and sensible/latent heat fluxes. Cloud cover, surface properties and atmospheric composition alter these fluxes.

Summary: Latitude sets the broad pattern; altitude, distance from sea, ocean currents, winds, topography, clouds, vegetation and human changes modify local and regional temperature distributions. Understanding these controls explains why places at the same latitude can have very different climates.

Fig 16 — Educational Diagram: Isotherms and temperature maps

Definition
An isotherm is a line drawn on a map that connects points having the same temperature at a specified time or period. Isotherms are a type of isopleth (lines of equal value) used to show spatial distribution and gradients of temperature.

Purpose and types of temperature maps
Temperature maps (isothermal maps) make it easy to visualize patterns such as latitudinal cooling, oceanic moderation, continental extremes and altitude effects. Common types include:

• Mean monthly isotherm maps (e.g., January, July)
• Mean annual isotherm maps
• Maps of daily or diurnal temperature range
• Maps showing temperature anomalies (difference from long-term average)

How isotherms are drawn
Temperature observations at stations are plotted, values are interpolated between stations and smoothed to draw continuous lines of equal temperature. Typical contour intervals are chosen to give clear patterns (e.g., 1°C, 2°C or 5°C depending on scale and variability).

General pattern and interpretation
- Isotherms roughly follow parallels (latitude control) but are often bent or displaced by other factors.
- Where isotherms are close together, the horizontal temperature gradient is steep (rapid change over short distance). Where they are widely spaced, the gradient is gentle.
- Comparing January and July isotherm maps highlights seasonal shifts: mid-latitude isotherms shift poleward in summer and equatorward in winter.

Factors affecting isotherm patterns

• Latitude (solar radiation): Primary control; temperatures decrease poleward.
• Altitude (height): Temperature decreases with elevation — isotherms bend upward over highlands (cold sinks at higher elevations).
• Continentality vs. maritime effect: Land heats and cools faster than ocean. Interiors show larger annual ranges and more tightly clustered extreme isotherms; coasts show moderated temperatures.
• Ocean currents: Warm currents (e.g., North Atlantic Drift) shift isotherms poleward; cold currents push isotherms equatorward.
• Wind and pressure systems: Prevailing winds transport air masses and distort isotherms (e.g., warm advection shifts them poleward).
• Aspect and slope: Sun-facing slopes are warmer than shaded slopes, producing local isotherm distortions.
• Cloud cover and albedo: Clouds reduce diurnal range and lower daytime maxima; surface cover (ice, vegetation) modifies heating.

Reading and using temperature maps
To interpret an isotherm map: identify the isotherm values and interval, note orientation and curvature of lines, locate steep gradients, compare seasonal maps (January vs July) and examine anomalies. Cross-sections (latitude or longitude) help quantify gradients and show vertical effects when combined with elevation.

Limitations and cautions
Isotherms are interpolations and are influenced by station density and smoothing method. Local microclimates (urban heat islands, valley inversions) may not appear on large-scale maps.

Educational tip
When practicing map-drawing, use consistent intervals, label lines clearly, show scale and date/time of observations, and mark major stations used for interpolation.

Fig 17 — Educational Diagram: Heat surplus and deficit

Definition: Heat surplus and heat deficit describe whether a place gains more heat energy than it loses (surplus) or loses more than it gains (deficit) over a given time period. They are based on the net radiation balance at Earth's surface.

Basic idea: The Earth receives shortwave solar radiation and emits longwave terrestrial radiation. Net radiation (R_n) = absorbed incoming solar radiation − outgoing terrestrial radiation (plus the net of incoming longwave). When R_n > 0 the surface has a heat surplus; when R_n < 0 it has a heat deficit.

Why it matters: Spatial and temporal patterns of surplus and deficit drive climate zones, temperature distribution, wind and ocean currents, vegetation patterns, and human energy needs. The tropics generally have a persistent surplus while polar regions show a deficit; mid-latitudes alternate with seasons.

Controls and causes: Latitude (solar angle and day length), seasonality (tilt of Earth), surface albedo (snow/ice reflect more), atmospheric composition and cloud cover (affect incoming/outgoing radiation), distribution of land and sea (oceans moderate temperature), and heat transport by atmosphere and oceans (which move surplus heat toward deficit regions).

Temporal pattern: On a monthly/seasonal basis many regions switch between surplus and deficit—for example mid-latitudes have surplus in summer and deficit in winter. On an annual basis, tropical regions usually show a persistent surplus, higher latitudes a sustained deficit.

Energy partitioning: Net radiation is partitioned into sensible heat (H), latent heat (LE, evaporation/condensation), and ground heat flux (G): R_n = H + LE + G. This explains why wet surfaces and oceans use much energy for evaporation (latent heat), moderating temperature rises even if net radiation is high.

Significance for temperature: Positive net radiation (surplus) tends to increase surface temperatures or fuel evaporation; negative net radiation (deficit) leads to cooling, freezing, and increased heating demand for humans.

Fig 18 — Educational Diagram: Temperature inversion

Definition: A temperature inversion is a stable atmospheric layer in which temperature increases with height (instead of the normal decrease). In other words, air near the surface is colder than the layer above it. Inversions suppress vertical mixing and lead to a host of weather and pollution effects.

How to recognise (simple test): Normally temperature falls with altitude (~6.5 °C per km). If dT/dz > 0 (temperature rises with height) then an inversion exists. The inversion has a base (nearer surface), a top, a depth and a strength (temperature difference between top and base).

Major types and formation mechanisms:

• Radiation (nocturnal) inversions: On clear, calm nights the ground loses heat by radiation, the surface cools rapidly and cools the overlying air by conduction. This produces a shallow surface inversion. Common in winters and in valleys.
• Valley (drainage) inversions: Cold dense air drains downslope into valleys and pools, forming a deep inversion layer above the cold pool.
• Advection (marine) inversions: When warm air moves over a colder surface (for example, warm air over a cold sea), the air near the surface is cooled producing an inversion aloft.
• Frontal inversions: Warm air riding up over a colder air mass (warm front) produces an inversion at the interface (warm air overriding cold).
• Subsidence inversions: Large-scale sinking (subsiding) air in high-pressure or anticyclonic regions warms adiabatically aloft, creating a relatively warm layer above cooler low-level air. These inversions can be extensive and persistent.

Effects and importance: Inversions stabilize the atmosphere by suppressing vertical motions. Consequences include:

• Trapping of pollutants and formation of smog in urban centers (poorer air quality).
• Formation and persistence of fog and low stratus clouds.
• Increased frost risk in agriculture, since surface temperatures drop and cold air pools.
• Suppression of convection and precipitation; weather remains calm and cloudless in strong inversions.
• Aviation hazards like low-level wind shear and poor visibility near the surface.

Key vocabulary: inversion base, inversion top, inversion depth (z_top - z_base), inversion strength (temperature difference across the layer).

Typical magnitudes: Surface inversions are often a few degrees Celsius over the lowest 50–500 m (e.g., 2–10 °C). Subsidence inversions may span hundreds to thousands of metres.

Fig 19 — Educational Diagram: Local and environmental effects

Definition: Local and environmental effects are the small-scale geographic and atmospheric factors that modify incoming solar radiation, heat balance and near-surface temperature patterns at a place. They act in addition to large-scale controls (latitude, season, continentality) and often produce pronounced local temperature contrasts.

How they work (mechanisms):

• Radiation balance modification: Surface properties (albedo, emissivity) and clouds/aerosols change the amounts of shortwave (solar) and longwave (thermal) radiation absorbed, reflected or emitted.
• Partitioning of net radiation: Net radiation (Rn) at the surface is divided into sensible heat (H), latent heat (LE) and ground heat (G). Local factors control the partition (e.g., wet soils increase LE, urban surfaces increase H).
• Advection and mixing: Horizontal transport of air (sea/land breezes, valley winds) moves heat and moisture, altering local temperatures.
• Topographic effects: Slope, aspect and elevation change the solar incidence angle and cooling/heating rates; cold-air drainage can trap cold air in valleys producing frost pockets.
• Surface storage and vegetation: Vegetation and soils buffer diurnal temperature swings by storing heat and evapotranspiring water.

Main local/environmental factors:

• Aspect and slope: South-facing slopes (Northern Hemisphere) receive more solar radiation and are warmer; steep slopes change incident angle and day-length exposure.
• Altitude (elevation): Temperature generally decreases with height (lapse rates); thin air also reduces greenhouse trapping.
• Proximity to water (continentality/coastal moderation): Water’s high heat capacity moderates temperature, reducing diurnal and seasonal extremes near coasts.
• Ocean currents: Warm/cold currents modify coastal climates (e.g., Gulf Stream warms NW Europe).
• Surface cover and albedo: Snow, ice, bare soil, vegetation and built surfaces reflect and absorb different amounts of solar radiation; high albedo (snow) cools, low albedo (dark asphalt) warms.
• Soil moisture and vegetation: Wet soils increase evaporation (higher LE), lowering air temperature; vegetation shades and transpires, cooling local air.
• Clouds and aerosols: Clouds reduce incoming shortwave radiation (cooling daytime) but increase downwelling longwave at night (warming), reducing diurnal range; aerosols scatter/absorb sunlight affecting surface heating.
• Urbanization (Urban Heat Island): Cities with concrete, reduced vegetation and waste heat are warmer than surrounding rural areas, especially at night.
• Local winds: Sea/land breezes, mountain-valley (anabatic/katabatic) winds move heat and create local temperature patterns.

Practical consequences: These effects determine microclimates important for agriculture (frost-prone hollows), human comfort (urban heat islands), ecosystem distribution (slope aspect), and local weather phenomena (sea-breeze thunderstorms).

Fig 20 — Educational Diagram: Measurement of radiation

What is being measured? Measurement of radiation in geography refers to measuring incoming solar (shortwave) radiation and outgoing/returned terrestrial (longwave) radiation at the Earth's surface. These measurements are essential to understand the Earth's heat balance, climate, weather, and for practical applications (solar energy, agriculture, building design).

Types of radiation relevant to measurement

• Direct (beam) radiation: solar rays arriving in a straight line from the Sun.
• Diffuse radiation: solar radiation scattered by atmosphere (clouds, aerosols).
• Global (total) radiation: sum of direct and diffuse on a horizontal surface.
• Terrestrial longwave radiation: thermal infrared emitted by surface and atmosphere.

Common instruments and how they work

• Pyrheliometer — measures direct beam irradiance (W m^-2) using a collimated detector mounted on a sun-tracker. Used to obtain direct normal irradiance.
• Pyranometer — measures global (direct + diffuse) radiation on a horizontal surface. A thermopile beneath a glass dome converts net heat flux to voltage proportional to irradiance.
• Pyrgeometer — measures incoming longwave (infrared) radiation from atmosphere.
• Net radiometer — measures net radiation (difference between incoming and outgoing shortwave and longwave) using upward- and downward-looking sensors.
• Sunshine recorder (Campbell–Stokes) — records hours of bright sunshine by focusing sunlight onto a card; useful for sunshine duration statistics (threshold commonly ~120 W m^-2).
• Actinograph / electronic sensors — continuous recording devices (digital) using photodiodes or thermopiles for time-series of irradiance.

Principles and important concepts

• Cosine law: intensity on a surface declines with the cosine of the angle between the beam and the surface normal: I = I₀ cos θ.
• Atmospheric attenuation: scattering and absorption by gases, water vapour, aerosols and clouds reduce solar irradiance reaching the surface.
• Albedo (α): fraction of incoming shortwave radiation reflected by a surface (0–1). Snow has high albedo; asphalt low.
• Net radiation (R_n): energy available at surface = incoming shortwave − reflected shortwave + incoming longwave − outgoing longwave.

Measurement accuracy and practical notes

• Instruments must be calibrated (standard reference often traceable to World Radiation Center). Thermopile sensors are sensitive to tilt, shading, cleanliness and dome condition.
• Pyrheliometers require accurate solar tracking; pyranometers require level installation and ventilation to avoid thermal offsets.
• Errors arise from cosine response, temperature dependence, spectral response and soiling.

Why these measurements matter (applications) Satellite estimates of solar radiation are validated with ground instruments; site selection and design of solar power plants; agricultural planning (evapotranspiration estimates); building thermal design; climate and energy balance studies.
